Wave Wire Marine

Welcome to Wave Wire Marine, your trusted partner in marine electrical design and engineering.

We are UK distributors for the full range of Oceanflex Marine Cables. Contact us today for a quote.

Marine Tinned Copper Cables

Specifications:

  • Cores manufactured to ISO 6722-1:2011 (class B) 105°C
  • Tinned Copper Conductors, PVC insulated
  • Suitable for use at temperatures from -40ºC to 105ºC with excursions up to 120ºC
  • Twins and multicore PVC sheathed at 70ºC
  • Suitable for 12v and 24v systems (maximum 60v)
  • Good resistance to petrol, diesel, lubricating oils and diluted acid
  • Very good resistance to moisture
  • PVC insulation saves weight and offers good resistance to abrasion and cut through
  • Cables are printed with the specification on the insulation
